HP M27 User Manual

4
2. Monitor features
This chapter provides an overview of the monitor’s features.
Features
60.5 cm (23.8 in) diagonal viewable screen area with 1920 × 1080 @ 60 Hz resolution, plus full screen
support for lower resolutions; includes custom scaling for maximum image size while preserving original aspect ratio
68.6cm (27inch) diagonal viewable screen area with 1920 × 1080 @ 60 hz resolution, plus full screen
support for lower resolutions includes custom scaling for maximum image size while preserving original aspect ratio
 Wide color gamut to provide coverage of NTSC color spaces
 Non glare panel with an LED backlight
 Wide viewing angle to allow viewing from a sitting or standing position, or moving from side to side
 Tilt and height adjustment capabilities for 23.8” and 27" monitor
 Landscape orientation only for 23.8” and 27” monitor
 Menu button and four on screen display (OSD) buttons, three that you can reconfigure to quickly allow
selection of the most commonly used operations
 Onscreen display (OSD) adjustments in several languages for easy setup and screen optimization
 Embedded 2w SPK per side in monitor
 Slide cover camera and microphone for online collaboration
 Energy saver feature to meet requirements for reduced power consumption
 Security cable slot on the rear of the monitor for an optional security cable
NOTE: For safety and regulatory information, refer to the Product Notices provided in your documentation kit.
To access the latest user guides or manuals for your product, go to http://www.hp.com/support and follow the
instructions to find your product. Then select Manuals.

HP M27 Specifications

General

Color gamut	99 %
Pixel pitch	0.3114 x 0.3114 mm
Screen shape	Flat
Pixel density	82 ppi
Display diagonal	27 \
Surface hardness	3H
Anti-glare screen	Yes
Maximum refresh rate	75 Hz
Contrast ratio (typical)	1000:1
Display diagonal (metric)	68.58 cm
Digital vertical frequency	48 - 75 Hz
Digital horizontal frequency	30 - 85 kHz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900, 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
HDMI version	1.4
DisplayPort version	1.2
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	130 W
Power consumption (standby)	0.5 W
Power consumption (typical)	20 W
Operating temperature (T-T)	5 - 35 °C
Package depth	211.4 mm
Package height	544 mm
Package weight	11300 g
Height adjustment	100 mm
Panel mounting interface	100 x 100 mm
Certification	Argentina S-Mark; BIS; CB; CCC; CE; CEL; CEL Grade 1; C-Tick; cTUVus; ENERGY STAR®; EPA; EUP Lot-5; EUP Lot-6; FCC; GS Mark; ICES; ISO 9241-307; KC/KCC; NOM; NOM (Mexico); RCM; UL/CSA-NTRL/ETL-NRTL Mark; VCCI; WEEE; EUP Lot-26; California Energy Commission (CEC); South Africa Energy; eStandby; Mexico LASE form; ICE; KES; PSE EAC; India BIS
Product color	Black, Silver
Country of origin	China
Market positioning	Home
Megapixel	5 MP
RMS rated power	4 W
Number of speakers	2
Sustainability certificates	ENERGY STAR
Depth	48.2 mm
Height	413 mm

Weight and Dimensions

Depth (with stand)	54.4 mm
Width (with stand)	61.2 mm
Height (with stand)	21.14 mm
Weight (with stand)	7300 g
Depth (without stand)	4.82 mm
Width (without stand)	612 mm
Height (without stand)	41.3 mm
