Solid state drive specifications
Performance
Sequential read (maximum) 250 MB/s
Sequential write (maximum) 70 MB/s
Characteristics
Interface SATA revision 2.6
Flash type MLC (LBG) NAND
Flash capacity 60 GB, 128 GB
Features ATA Security; ATA-7 ;SATA 2.6; DIPM
Electrical specifications
DC supply voltage 5.0 V ±5%
Standby current 130 mA (typical)
Active current Read = 210.1 mA (average)
Write = 225.9 mA (average)
Environmental specifications
Operating temperature 0°C to +70°C (32°F to 158°F)
Storage temperature -55°C to +95°C (-67°F to 203°F)
Operating altitude up to 24,384 m (80,000 feet)
Humidity 5% to 90% non-condensing
Shock 1500 g
Vibration (operating) 20 g peak, 10~2000 Hz
Physical specifications
Connector 7+15 pin SATA connector
Weight 86 g (3.03 oz)
Dimensions (height × width) 9.5 × 70 mm (0.37 × 2.75 in)
Regulations and compliance RoHS, China RoHS, SGS ROHS, FCC, CE
UL – PCB Only
Solid state drive specifications 105
