HP OMEN 25 Maintenance And Service Guide

4
Side and bottom components on the rear panel
To identify the components on the rear of the monitor, use this illustration and table.
Rear of monitor showing location of controls and connectors
Table 1-1: Front components and their descriptions
Component
Function
1
Power button
When the monitor is off, press the button to turn on
the monitor.
2
OK button
Press to open the OSD menu, select a menu item
from the OSD, or close the OSD menu. An indicator
is activated above the OK button when the OSD
menu is open.
3
Function buttons
Use these buttons to navigate through the OSD
menu based on the indicators above the buttons
that are activated when the OSD menu is open.
4
Security cable slot
Connects a security cable from the monitor to a
stationary object
5
USB 3.x (2) (downstream)
Connect optional USB devices to the monitor.
6
USB 3.x (upstream)
Connects the USB hub cable from the source device
to the monitor.
7
Power connector
Connects an AC adapter.
8
HDMI ports (2)
Connect the HDMI cables from source devices to the
monitor.
9
DisplayPort
Connects the DisplayPort cable from the source
device to the monitor.
10
Audio headphone/variable line-out jack
Connects optional powered stereo speakers,
headphones, earbuds, a headset, or a television

HP OMEN 25 Specifications

General

3D	No
Panel type	TN
Pixel pitch	0.283 x 0.283 mm
Screen shape	Flat
Display diagonal	24.5 \
Display technology	LED
Native aspect ratio	16:9
Viewable size, vertical	302.6 mm
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	543.7 mm
Display brightness (typical)	400 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
Certification	CE; ICES; VCCI; FCC; C-Tick; CB; TUV-GS; ISO-9241-307; cTUVus; TUV LBL; CCC; CEL; BSMI; KCC; Australia MEPS; E-standby; PSB; ISC; Microsoft WHQL Certification (Windows 10, Windows 8.1 and Windows 7); SmartWay Transport Partnership - NA only
Product color	Black
Country of origin	China
Market positioning	Gaming
VESA mounting	-
Tilt angle range	-5 - 23 °
USB hub version	3.2 Gen 1 (3.1 Gen 1)
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	3
HP segment	Home
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	40 W
Annual energy consumption	35.3 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	30 W
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 70 %
Cables included	AC, HDMI, DisplayPort, USB
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	227.5 mm
Width (with stand)	569 mm
Height (with stand)	407.9 mm
Weight (with stand)	4600 g
Depth (without stand)	62.8 mm
Height (without stand)	346.2 mm
Weight (without stand)	3550 g
