HP OMEN 27s User Manual

8
3 Illustrated parts catalog
To identify the monitor major components, use this illustration and table.
Item
Description
Qty
1
PANEL
1
2
MIDDLE_FRAME
1
3
SPEAKER 3W
1
4
SCREW M3 4
15
5
INSULATING SHEET 240.2*168*10mm
1
6
SCREW M3 6
1
7
CONVERTER BOARD
1
8
ADAPTER BOARD NA
1
9
MAIN BOARD
1
10
MAINFRAME
1
11
CONNECTOR BOARD
1
12
SCREW Q2 3.4
2
13
KEY BOARD
1
14
REAR_COVER
1
