HP P2000 G3 User Manual

HP P2000 G3 SAS MSA System User Guide 17
2Components
Front panel components
P2000 G3 SAS MSA System LFF
P2000 G3 SAS MSA System SFF
1 Enclosure ID LED
2 Disk drive Online/Activity LED
3 Disk drive Fault/UID LED
4 Unit Identification (UID) LED
5 Heartbeat LED
6 Fault ID LED
P2000
1
4
7
10
3
6
9
12
132
4
5
6
1 Enclosure ID LED
2 Disk drive Online/Activity LED
3 Disk drive Fault/UID LED
4 Unit Identification (UID) LED
5 Heartbeat LED
6 Fault ID LED
P2000
1
3
2
4
5
6
Left ear
Right ear
Left ear
Right ear
