2 External component identication
Right side
Component Description
(1) Memory card reader Reads optional memory cards that enable you to store, manage, share, or access
information.
To insert a card:
1. Hold the card label-side up, with connectors facing the computer.
2. Insert the card into the memory card reader, and then press in on the card
until it is rmly seated.
To remove a card:
▲ Press in on the card, and then remove it from the memory card reader.
(2) Drive light
●
Blinking white: The hard drive is being accessed.
●
Amber: HP 3D DriveGuard has temporarily parked the hard drive.
(3) USB 3.0 SuperSpeed port Connects a USB device, such as a cell phone, camera, activity tracker, or
smartwatch, and provides high-speed data transfer.
NOTE: Cables and/or adapters (purchased separately) may be required.
(4) HDMI port Connects an optional video or audio device, such as a high-denition television,
any compatible digital or audio component, or a high-speed High-Denition
Multimedia Interface (HDMI) device.
(5) RJ-45 (network) jack/status
lights
Connects a network cable.
●
White: The network is connected.
●
Amber: Activity is occurring on the network.
(6) Power connector Connects an AC adapter.
(7) Battery light
●
White: The AC adapter is connected and the battery is fully charged.
●
Blinking white: The AC adapter is disconnected and the battery has reached
a low battery level.
●
Amber: The AC adapter is connected and the battery is charging.
●
O: The battery is not charging.
Right side 11
