3–12 Maintenance and Service Guide
Illustrated parts catalog
Plastics Kit
Mass storage devices
Item Description Spare part number
Plastics Kit: 513517-001
1 Hard drive cover (includes 4 captive screws, secured by C-clips)
2 Wireless module compartment cover (includes 1 captive screw, secured by a C-clip)
Item Description Spare part number
1 Hard drive (includes connector and bracket)
500-GB, 5400-rpm 517848-001
320-GB, 5400-rpm 517847-001
250-GB, 5400-rpm 517846-001
160-GB, 5400-rpm 517845-001
Hard Drive Hardware Kit (not illustrated, includes connector, bracket, and screws) 531204-001
2 Optical drive (includes bezel and bracket)
DVD±RW and CD-RW SuperMulti Double-Layer Combo Drive with LightScribe 517850-001
Blu-ray ROM with LightScribe DVD±R/RW SuperMulti Double-Layer Drive 517852-001
