4–42 Maintenance and Service Guide
Removal and replacement procedures
Processor
✎
The processor spare part kit includes replacement thermal material.
Before removing the processor, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the computer on,
and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the following components:
a. Remove the battery (see “Battery” on page 4-7)
b. Optical drive (see “Optical drive” on page 4-8)
c. Hard drive (see “Hard drive” on page 4-10)
d. Keyboard (see “Keyboard” on page 4-17)
e. Switch cover (see “Switch cover” on page 4-20)
f. Power button board (see “Power button board” on page 4-22)
g. Display assembly (see “Display assembly” on page 4-23)
h. Top cover (see “Top cover” on page 4-30)
i. Bluetooth module (see “Bluetooth module” on page 4-35)
j. System board (see “System board” on page 4-36)
k. Fan/heat sink assembly (see “Fan/heat sink assembly” on page 4-38)
Description Spare part number
Intel Core2 Duo P8700 2.53-GHz processor (3-MB L2 cache) 507960-001
Intel Core2 Duo P7450 2.13-GHz processor (3-MB L2 cache) 507965-001
Intel Core2 Duo T6600 2.20-GHz processor (3-MB L2 cache) 513593-001
Intel Core2 Duo T6400 2.06-GHz processor (3-MB L2 cache) 513592-001
Intel Pentium T3400 2.16-GHz processor (1-MB L2 cache) 509549-001
Intel Pentium T4200 2.06-GHz processor (2-MB L2 cache) 531599-001
Intel Celeron-M 585 2.16-GHz processor (1-MB L2 cache) 519898-001
Intel Celeron T1700 1.83-GHz processor (1-MB L2 cache) 534084-001
Intel Celeron T1600 1.66-GHz processor (1-MB L2 cache) 532324-001
