Silver Phillips PM2.0×3.0 screw
Color Quantity Length Thread Head width
Silver 5 3.0 mm 2.0 mm 4.5 mm
Where used:
(1) One screw that secures the display release hook to the base enclosure
(2) One screw that secures the Bluetooth module to the base enclosure
Where used: 3 screws that secure the pen eject assembly and pen holder to the base enclosure
94 Chapter 7 Screw listing
