System board
Description Spare part number
System board equipped with an Intel Atom Z3736F 1.33-GHz quad core processor (SoC), a graphics subsystem with UMA memory, and
2.0-GB of system memory
Equipped with 64-GB of eMMC system storage, T-Mobile WWAN capability, and the Windows 8
Professional operating system
808084-601
Equipped with 64-GB of eMMC system storage, T-Mobile WWAN capability, and the Windows 8 Standard
operating system
808084-501
Equipped with 64-GB of eMMC system storage, WWAN capability, and the Windows 8 Professional
operating system
806368-601
Equipped with 64-GB of eMMC system storage, WWAN capability, and the Windows 8 Standard
operating system
806368-501
Equipped with 64-GB of eMMC system storage and the Windows 8 Professional operating system 805091-601
Equipped with 64-GB of eMMC system storage and the Windows 8 Standard operating system 805091-601
Equipped with 32-GB of eMMC system storage and the Windows 8 Professional operating system 805090-601
Equipped with 32-GB of eMMC system storage and the Windows 8 Standard operating system 805090-601
Before removing the system board, follow these steps:
1. Turn off the tablet. If you are unsure whether the tablet is off or in Hibernation, turn the tablet on, and
then shut it down through the operating system.
2. Disconnect the power from the tablet by unplugging the power cord from the tablet.
3. Disconnect all external devices from the tablet.
4. Remove the back cover (see Back cover on page 14).
5. Remove the middle frame and battery (see Middle frame and battery on page 15).
6. Remove the rear-facing webcam (see Rear-facing webcam on page 19).
Remove the system board:
1. Remove the shield (1) that covers the WLAN antenna cable connectors.
20 Chapter 5 Removal and replacement procedures
