HP S430c User Manual

17
CN1102
For USB Board
This procedure includes USB Type-C and USB connectors.
The connectors are on the USB board (board part number CBPCMEDH0Q4).
The connector identifiers are as follows:
Connector
Location
TYPE-C 1
CN5101
TYPE-C 2
CN5401
USB
CN1101
USB
CN1102
USB
CN1103
USB
CN1104
Before repairing connectors, follow these steps:
▲ Prepare the monitor for disassembly. See Preparation for disassembly on page 11.
Board
USB Board
CN5101
CN5401
CN1101
CN1104
CN1103

HP S430c Specifications

General

HD type	WUXGA
Panel type	VA
Pixel pitch	0.274 x 0.274 mm
Pixel density	92 ppi
Display diagonal	43.4 \
Display resolution	3840 x 1200 pixels
Display technology	LED
Native aspect ratio	32:10
Maximum refresh rate	60 Hz
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	3000:1
Display number of colors	-
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 3840 x 1200
HDMI	Yes
USB hub version	3.2 Gen 2 (3.1 Gen 2)
DisplayPort version	1.2
USB Type-C downstream ports quantity	2
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
AC input voltage	100 - 240 V
Power consumption (standby)	0.5 W
Power consumption (typical)	80 W
Tilt angle range	-5 - 20 °
Panel mounting interface	100 x 100 mm
Certification	BSMI; CB; CCC; CE; CEL; cTUVus; EAC; EPA; FCC; ICES; ISO 9241-307; KCC; PSB; TCO Certified; UV-S; UL; VCCI; WEEE; ISC
Product color	Black, Silver
Market positioning	Gaming
Cables included	AC, HDMI, USB Type-C to USB Type-A, USB Type-C to USB Type-C
HP segment	Business
Package type	Box
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	256 mm
Height (with stand)	491 mm
Depth (without stand)	140.8 mm
Width (without stand)	1057 mm
Height (without stand)	361.9 mm
Weight (without stand)	14300 g
