Table 3-1 Computer major components and their descriptions
Item Component Spare part number
(1) Display assembly: Spare parts for the display assembly are available at the subcomponent level only. For more display
assembly spare part information, see Display assembly components on page 16.
(2) Keyboard/top cover (includes keyboard cable):
For a list of keyboard country codes, see Keyboard/top cover on page 44.
For use in blue models L59910-xx1
For use in white models L59908-xx1
For use in pink models L59909-xx1
For use in black models L59911-001
(3) Touchpad
For use in blue models L64224-001
For use in white models L64226-001
For use in black models L64225-001
For use in pink models L64227-001
(4) Touchpad cable 905563-001
(5) RTC battery 857380-001
(6) Battery, 3-cell, 41 Whr 844203-855
(7) Battery cable 905566-001
(8) Heat sink L61888-001
(9) WLAN module
Intel Realtek RTL8821CE 802.11ac 1 × 1 Wi-Fi + Bluetooth® 4.2 (MU-MIMO supported) L17365-005
Realtek RTL8822BE 802.11ac 2 × 2 Wi-Fi + Bluetooth 4.2 Combo Adapter (MU-MIMO supported) 924813-855
Realtek 802.11ac 2 × 2 + Bluetooth 5.0 L44796-005
(10) Speakers (includes cable) L61391-001
(11) System board (includes integrated processor, thermal grease, and thermal pads):
AMD A6-9220e processor with 64 GB of eMMC memory L62002-601
AMD A4-9120e processor with 64 GB of eMMC memory L62001-601
AMD A4-9120e processor with 64 GB of eMMC memory (fTS) L63884-601
AMD A4-9120e processor with 32 GB of eMMC memory L62000-601
AMD A4-9120e processor with 32 GB of eMMC memory (fTS) L63883-601
(12) Power button board 905579-001
(13) Power button board cable L61392-001
(14) Power connector (DC in) cable 810327-004
(15) Base enclosure
For use in blue models L61884-001
14 Chapter 3 Illustrated parts catalog
