Memory module
Table 5-3 Memory module description and part number
Description Spare part number
Memory module, 4 GB (DDR4, 2666 MHz) L10598-855
Before removing a memory module, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 23).
2. Remove the bottom cover (see Bottom cover on page 24).
3. Disconnect the battery cable from the system board (see Battery on page 25).
To remove a memory module:
1. Spread the retaining tabs (1) on each side of the memory module slot to release the memory module.
(The memory module tilts up.)
2. Remove the memory module (2) by pulling it away from the slot at an angle.
Reverse this procedure to install a memory module.
26 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
