NOTE: Disconnect the battery cable carefully; pulling too hard can break the system board connector.
1. Disconnect the battery cable (1) from the system board.
2. Release the battery tabs and tape (2) holding the battery.
NOTE: Be careful not to bend the battery as you lift it.
3. Lift up the battery (3) to release it.
4. Remove the battery (4).
Reverse this procedure to install the battery.
Rear-facing webcamera
Description Spare part number
Rear-facing webcamera (includes cable) 796787-001
Before removing the rear-facing webcamera, follow these steps:
1. Turn off the tablet. If you are unsure whether the tablet is off or in Hibernation, turn the tablet on, and
then shut it down through the operating system.
2. Disconnect the power from the tablet by unplugging the power adapter cord from the tablet.
3. Disconnect all external devices from the tablet.
4. Remove the back cover (see Back cover on page 13).
16 Chapter 5 Removal and replacement procedures
