Speakers
Description Spare part number
Speakers (includes cable) 905565-001
Before removing the speakers, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the bottom cover (see Bottom cover on page 24).
5. Remove the battery (see Battery on page 25).
Remove the speakers:
1. Disconnect the speaker cable (1) from the system board.
2. Lift the speakers from the computer (2).
Reverse this procedure to install the speakers.
32 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
