TouchPad
Description Spare part number
TouchPad for use in blue models 905691-001
TouchPad for use in white models 910178-001
TouchPad for use in black models 928421-001
TouchPad for use in gray models 933606-001
TouchPad for use in pink models L16703-001
TouchPad for use in purple models L16708-001
TouchPad cable 905563-001
Before removing the TouchPad, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the bottom cover (see Bottom cover on page 24).
5. Disconnect the battery cable from the system board (see Battery on page 25).
6. Remove the system board (see System board on page 33).
Remove the TouchPad:
1. Remove the three Phillips PM2.0×3.0 screws (1) that secure the TouchPad bracket to the computer, and
the lift the bracket from the computer (2).
2. Disconnect the cable from the TouchPad (3).
Component replacement procedures 35
