RJ-11 (modem)
Pin Signal
1Unused
2Unused
3Ring
4Tip
5Unused
6Unused
RJ-45 (network)
Pin Signal
1 Transmit +
2 Transmit -
3Receive +
4 Unused
5 Unused
6Receive -
7 Unused
8 Unused
RJ-11 (modem) 101
