HP Z32k G3 Maintenance And Service Guide

19
IMPORTANT:
• Repair Condition: Connector repair is only for out of warranty.
• Repairing must operate by professional repairers (Note) in repair center, not applicable for end user.
• Electrostatic protection is required when component replacement is required.
• The monitor meets ROHS, please use Lead-free solder wire for soldering.
• If Connector need to replace, must check specification and part number whether match the BOM and location.
• If connector need to replace, please insert new parts carefully because the near pin may cause short circuit by
inappropriate operate.
• DO NOT allow any liquid on the board. Water and moisture may cause short-circuit to the electronic components and
lead to malfunctions.
• The fusion point of Lead-Free solder is requested. Repairing with conventional lead wire may cause damage.
• Work quickly to avoid overheating the circuit board as soon as you confirm the steady soldering condition.
• Keep the soldering iron tip clean and well tinned and when replacing parts.
• A close inspection of the circuit board revealed look in good condition.
• After repaired, must connect source to each port to check Main board function is ordinary.
Note: (The requirement of professional repairers’ regulation by ERP lot5)
1) The professional repairer has the technical competence to repair electronic displays and complies with the
applicable regulations for repairers of electrical equipment in the Member States where it operates. Reference to
an official registration system as professional repairer, where such system exists in the Member States concerned,
shall be accepted as proof of compliance with this point.
2) The professional repairer is covered by insurance covering liabilities resulting from its activity, regardless of
whether this is required by the Member State.
HDMI connector CN5001
Repair the HDMI connector:
1) Use a soldering iron and a de-soldering pump to remove as much solder as possible from the pin.
2) Use a hot air gun to melt the solder on the pins.

HP Z32k G3 Specifications

General

Color depth	10 bit
Pixel pitch	0.18 x 0.18 mm
Screen shape	Flat
Pixel density	140 ppi
Backlight type	Edge LED
Display diagonal	31.5 \
Surface hardness	3H
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	29 - 60 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 135 kHz
sRGB coverage (typical)	100 %
Display bezel technology	Micro-Edge
Display number of colors	1.07 billion colors
Display brightness (typical)	400 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1440, 3840 x 2160
Pivot angle	-90 - 90 °
Number of OSD languages	11
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, DUT, ENG, ESP, FRE, ITA, JPN, POR, RUS
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	180 W
Power consumption (standby)	0.5 W
Power consumption (typical)	35 W
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, DisplayPort, HDMI, Thunderbolt, USB Type-A to USB Type-B
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	1
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.4
USB upstream port type	USB Type-B, USB Type-C
USB Power Delivery up to	100 W
USB Type-A downstream ports quantity	4
Sustainability certificates	ENERGY STAR
HP segment	Business
Package depth	185 mm
Package width	816 mm
Package height	504 mm
Package weight	13700 g
Product color	Black, Silver

Weight and Dimensions

Depth (with stand)	217 mm
Width (with stand)	713.5 mm
Height (with stand)	604.9 mm
Weight (with stand)	9000 g
Depth (without stand)	47 mm
Height (without stand)	415.9 mm
