1
Power jack
NOTE
Use a DC power cable to connect the router
to an external power source.
2 Audio interface
3 Two video interfaces 4 USB interface (host)
5 GPS antenna interface 6 3G/LTE antenna interface
7 WAN interfaces: two GE electrical
interfaces
8 Two Wi-Fi antenna interfaces
9 USB interface (OTG) 10 Two SIM card slots
NOTE
l The SIM card slots support double-card
single-standby.
l Industrial SIM cards are recommended
for the router.
l The mounting hole above the SIM card
slots is used to fix the SIM card cover
with a screw.
11 Micro SD card slot 12 CONSOLE interface
Huawei AR500&AR510&AR530&AR550&AR2500
Series Industrial Switch Routers
Product Description
4 Appearance
Issue 02 (2016-11-25) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
61
