Figure 4-23 AR550C-4GE appearance
0
MGMT
1
23
4 5
DC1 DC2 RUN ALM
2.5 GE
GE
21
DC1 DC2
CONSOLE
12-48 V; 1.5-0.4 A
DI
7 8
3 45
6
1
LAN interfaces: four GE electrical
interfaces
NOTE
GE0 is a management interface and is used to
upgrade the router.
2 WAN interfaces: two 2.5GE optical
interfaces
3 DO interface 4 DI interface
5 Two DC power sockets 6 Ground point
NOTE
To protect the router from lightning and
interference, reliably ground the router using
a Ground Cable.
7 Console interface 8 USB interface
4.4.2 AR550C-2C6GE
Appearance and Structure
Figure 4-24 shows the appearance of the AR550C-2C6GE router.
Huawei AR500&AR510&AR530&AR550&AR2500
Series Industrial Switch Routers
Product Description
4 Appearance
Issue 02 (2016-11-25) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
76
