3 Installation
Before installing the ODU, please verify that you have all the items listed in 1 What You Need.
If any of the items is missing or damaged, please contact your LTE service provider.
3.1 Select a Location.
The ODU should be pole-mounted outdoors and aligned so its antenna faces the nearest LTE
base station. When selecting a suitable location for the unit, consider these guidelines:
1. When choosing a location to install the ODU, please note that the ODU's front panel
should point towards your service provider's nearest base station.
You do not need to be able to see the base station from the ODU's position. However, if
you experience the difficulties with signal reception, a Line of Slight (LoS) connection
may have better result.
2. Place the ODU away from power and telephone lines.
3. Avoid placing the ODU nearby any metallic reflective surfaces.
4. Be sure to ground the ODU with an appropriate grounding wire by attaching it to the
grounding screw on the unit and to a good ground connection.
3.2 Mounting the Device
Step 1 Preparation.
1. SIM card is inserted in the SIM slot by following the direction mark.
2. Make sure the grounding screw on the rear panel.
3. Connect a Grounding cable between the ground terminal of the ODU (marked ) and a
ground connection. (Suggest to with Ethernet lighting protector between Ethernet cable
and indoor PoE supplier for better lighting and surge protection).
4. For additional lightning protection, it is recommended to use a lightning arrestor
immediately before the Ethernet cable enters the building.
