Huawei B683 Quick Start

7
(Optional) Connecting to a Telephone
If you want to use the device to make voice calls, connect the device to a
telephone, as shown in the following figure.
Note:
 Skip this section if you do not plan to use the device's voice services.
 Radio signals can interfere with telephone call connection and quality. To
eliminate the risk of possible interference, place the telephone at least 1
meter (3.28 feet) away from the device.
Connecting to a Computer
Use an Ethernet cable to connect a computer to one of the device's LAN
ports, as shown in the following figure.
When the connection between the device and the computer is set up, the
device's corresponding LAN indicator turns on.
Ensure that the Ethernet cable is not longer than 100 meters (328 feet).

Huawei B683 Specifications

General

Device type	Cellular network router
Market positioning	Home
Data network	EDGE, GPRS, GSM, HSPA+, HSUPA, WCDMA
Number of SIM cards	1
Ethernet LAN data rates	100 Mbit/s
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
Web-based management	Yes
Input voltage	100 - 240 V
Power consumption (typical)	10 W

Weight and Dimensions

Weight	300 g
