4.1 IFS06
An Indoor Floor installation Support (IFS06) is used for installing indoor RRUs.
Exterior
Figure 4-1 shows an IFS06.
Figure 4-1 IFS06
Function
l It can be installed on the ground.
l The upper and lower adjustable beams on an IFS06 can be moved up and down to fit for
heights of RRUs.
Structure
The IFS06 consists of the main frame, cable tray, upper and lower adjustable beams, and front
and rear feet, as shown in Figure 4-2.
DBS3900
RRU3252/RRU3256 Hardware Description 4 RRU Auxiliary Devices
Issue Draft A (2012-11-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
23
