Table 1-6 HG8240H device parameters
Parameter Specifications
Dimensions (length x width x height) 176 mm x 138.5 mm x 28 mm
Weight About 500 g
Working environment Operating temperature: 0ºC to +40ºC
Environment humidity: 5% RH to 95% RH
(non-condensing)
Pressure environment: 86 kPa to 106 kPa
Altitude: 2000 m
Power specifications Power adapter input: 100 V AC to 240 V AC,
50 Hz to 60 Hz
System power supply: 11 V DC to 14 V DC,
1 A
Power consumption
l Static power consumption: 4 W
l Maximum power consumption: 10 W
1.4.2 HG8242H
Introduced the appearance, interfaces, LEDs, and device parameters of the HG8242H.
Appearance
Figure 1-7 Appearance of the HG8242H
Port/Button
Figure 1-8 and Figure 1-9 show the ports on the rear panel and side panel of the HG8242H
respectively.
EchoLife HG8242H/HG8240H/HG8240F/HG8110H GPON
Terminal
Product Description 1 Introduction
Issue 01 (2013-08-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
8
