Huawei EchoLife HG8240F User Manual

1.4.4 HG8240F
Introduced the appearance, interfaces, LEDs and device parameters of the HG8240F.
Appearance
Figure 1-16 Appearance of the HG8240F
Port/Button
Figure 1-17 and Figure 1-18 show the ports on the rear panel and side panel of the HG8240F
respectively.
Figure 1-17 Ports and buttons on the rear panel of the HG8240F
Table 1-18 Description of ports and buttons on the rear panel of the HG8240F
Port/Button
Function
LAN1 to LAN4
Indicates auto-sensing 10/100M Base-T Ethernet ports (RJ-45),
used to connect to PCs or IP set-top boxes (STBs).
EchoLife HG8242H/HG8240H/HG8240F/HG8110H GPON
Terminal
Product Description 1 Introduction
Issue 01 (2013-08-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
17
