4.1 GPON Port Specifications
This topic describes specifications and standards compliance of the GPON interfaces.
Table 4-1 GPON port specifications
Parameter Specifications
Transmission rate Rx: 2.488 Gbit/s
Tx: 1.244 Gbit/s
Connector SC/APC
Maximum reach 20 km
Standard compliance ITU-T G.984.2 CLASS B+
Center wavelength Tx: 1310 nm
Rx: 1490 nm
Tx optical power 0.5 dBm to 5.0 dBm
Extinction ratio > 10 dB
Minimum receiver sensitivity -27 dBm
Maximum overload optical power -8 dBm
4.2 FE Port Specifications
This topic describes the specifications and standards compliance of Fast Ethernet (FE) ports.
Table 4-2 Specifications of a FE port
Parameter
Specifications
Connector type RJ-45
Port rate 10 Mbit/s or 100 Mbit/s
Maximum transmission distance 100 m
Working mode Auto-adaptive 10 Mbit/s or 100 Mbit/s
Cable specifications Category 5 UTP
Compliant standard IEEE 802.3i
IEEE 802.3u
EchoLife HG8242H/HG8240H/HG8240F/HG8110H GPON
Terminal
Product Description 4 Port Specifications
Issue 01 (2013-08-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
28
