Appendix
Technical Specifications
Item Specifications
Power supply 12 V DC, 0.5 A
Power consumption < 5 W
Ambient operating
temperature
0°C to 40°C
Ambient humidity 5% to 95% RH (non-condensing)
Dimensions (H x W x D)
31.5 mm x 118 mm x 100 mm (1.24 in. x 4.65 in. x 3.94 in.), antenna
excluded
Weight About 360 g
DSL standard
ADSL standard
ITU G.992.1 (G.dmt)
ITU G.994.1 (G.hs)
ANSI T1.413 Issue 2
ADSL2 standard
ITU G.992.3 (G.dmt.bis) Annex A
ITU G.992.3 (G.dmt.bis) Annex L
ITU G.992.3 (G.dmt.bis) Annex M
ADSL2+ standard
ITU G.992.5 (G.dmt.bitplus) Annex A
ITU G.992.5 (G.dmt.bitplus) Annex M
WLAN standard 802.11b, 802.11g, and 802.11n (2.4 GHz)
DSL transmission rate
G.dmt
T1.413
Downlink: 8 Mbit/s
Uplink: 896 kbit/s
ADSL
Downlink: 12 Mbit/s
Uplink: 1024 kbit/s
ADSL2+
Downlink: 24 Mbit/s
Uplink: 1024 kbit/s
Wireless transmission rate
802.11b Up to 11 Mbit/s
802.11g Up to 54 Mbit/s
802.11n (2T2R
antenna technology)
Up to 300 Mbit/s
