14
4.2 Setting Up a Wireless Connection Manually
If your network adapter does not support the WPS function, you can set up a
wireless connection between your PC and the HG532e manually.
Takes Windows XP as an example, to set up a wireless connection between
your PC and the HG532e manually, do as follows:
Step 1 Enable the wireless configuration service provided by Windows XP.
1. Right-click My Computer, and then choose Manage from the
shortcut menu.
2. In the Computer Management window, choose Computer
Management (Local) > Services and Applications > Services.
3. From the services listed in the right pane of the Computer
Management window, right-click Wireless Zero Configuration, and
then choose Properties from the shortcut menu.
4. In the Wireless Zero Configuration Properties (Local Computer)
dialog box, check whether Service status is Started. If not, click
Start.
5. Click OK to close the dialog box, and then close the Computer
Management window.
Step 1 Record the WLAN name and the WLAN access password.
Step 2 Configure the wireless network connection on your computer.
1. Choose Start > All Programs > Accessories > Communications >
Network Connections.
2. In the Network Connections window, right-click Wireless Network
Connection to display a shortcut menu, and then choose Properties
from the shortcut menu.
3. In the Wireless Network Connection Properties dialog box, select
Wireless Networks.
4. Select Use Windows to configure my wireless network settings.
5. Click View Wireless Networks.
6. In the Wireless Network Connection dialog box, select the WLAN
with the same name as the WLAN name that you have recorded from
The WLAN name (SSID) and WLAN access password of the HG532e
are preset before delivery. You can find them from the label on the
bottom of the HG532e.
