11 Appendix

Technical Specifications

Item Specifications

Power supply 12 V DC, 2 A

Power consumption < 24 W

Ambient operating

temperature

0°C to 40°C

Ambient humidity 5% to 95% RH (non-condensing)

Dimensions (H x W x D) 185 mm x 37 mm x 240 mm, exclude the installer

Weight < 350 g

DSL standard

VDSL standard

ITU G.993.2 (G.dmt) Annex B

8a, 8b, 8c, 8d, 12a, 12b, 17a

ADSL standard

ITU G.992.1 (G.dmt)

ITU G.992.2 (G.lite)

ITU G.994.1 (G.hs)

ANSI T1.413 Issue 2

ADSL2 standard ITU G.992.3 (G.dmt.bis) Annex L

ADSL2+ standard ITU G.992.5 (G.dmt.bitplus) Annex M

WLAN standard

802.11b, 802.11g, 802.11n (2.4 GHz)

and 802.11ac (5 GHZ)

Wireless transmission rate

802.11b Up to 11 Mbit/s

802.11g Up to 54 Mbit/s

802.11n (2T2R

antenna

technology)

Up to 300 Mbit/s

802.11ac (3T3R

antenna

technology)

Up to 1.3 Gbit/s
