2 Hardware Installation
Selecting an Installation Location
Place the HG659 on a well-ventilated even surface without exposure to direct sunlight. For the best
possible performance, take note of the following:
> Make sure there are no obstacles, such as concrete or wooden walls, between the computer
and HG659.
> Ensure that the computer and HG659 are far from electric appliances that generate strong
magnetic or electric fields, such as microwave ovens.
Installing the HG659 on a DSL Broadband Network
In some communities, Internet service providers use telephone lines to provide broadband access
services.
If you have subscribed to digital subscriber line (DSL) broadband, you can connect the HG659 to a
telephone port for Internet access.
Connect your devices in the sequence indicated in the following figure.
When configuring the HG659 for the first time, use an Ethernet cable to connect the HG659
to a computer.
1 Telephone wall jack 2 Power adapter 3 Splitter
4 Telephone 5 Set-top Box 6 Laptop computer
7 Desktop computer 8 Smart Phone 9 Pad
a LINE port b MODEM port c PHONE port
