Figure 1 Installing an RRU RF jumper
NOTICE:
On AC-powered electric railways, such as high-speed railways, when leaky cables are
connected to RRUs installed in tunnels, high-voltage-resistance DC blocks must be installed
between RRU RF jumpers and the leaky cables to protect the RRUs against damage.
2. Connect the other end of the RRU RF jumper to the external antenna system.
NOTICE:
Before installation, check whether the connector at the other end is a 4.3-10 straight male
connector or DIN male connector.
3. Waterproof the connectors of the RF jumper by referring to Figure 2.
