Huawei RRU5909 User Manual

Figure 2 RRU cabling cavity
(1) Cover plate of the cabling cavity
(2) Cabling cavity
(3) Label for preparing the power cable
(4) Cable clip
(5) Power cable trough
(6) Waterproof block
(7) Optical cable trough
-
-
3. Remove the waterproof block.
NOTE:
Remove only the waterproof blocks for the cables to be installed.
Parent Topic: Installing RRU Cables
Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
< Previous topic Next topic >
7.2.2.8.9 Installing a CPRI Optical Fiber
This section describes the procedure for installing a CPRI optical fiber.
Prerequisites
Before the installation, single-mode optical modules can be distinguished from multimode optical
modules in either of the following ways:
