Thank you for purchasing a Huawei S series switch. This guide describes how to install S2700, S3700,
S5700, and S6700 series switches. It also explains how to log in to your switch for the first time.
For more information, see the for your switch on the
Huawei support website.
The installation, cable connection, and login methods for most S series switches are similar. This
guide uses the S5700-24TP-SI-AC as an example.
Figures in the document are for reference only and may be dierent from actual devices.
Any procedural dierences between models are specified at the start of each section.
1 About This Guide
Chassis (with the product model on the nameplate)
Power cable (Power cables are delivered with the
switch if the switch is equipped with built-in
power supply or pluggable power modules, and
are delivered with power modules in other cases.)
Installation accessory package:
-
- Rubber pads
- Chassis ground cable
- Dust plugs
- Warranty Card
- Mounting brackets
- Screws
The numbers and types of items in the installation accessory package dier for dierent product models.
Some switches have dust plugs delivered with them. Keep the dust plugs properly and use them to protect idle optical ports.
NOTE
2 Packing List
3 Safety Guidelines
To ensure personal and equipment safety, observe all the safety precautions on the equipment
and in this document. WARNING and CAUTION items do not cover all the safety precautions and
are only supplementary to the safety precautions.
Follow all the safety precautions and instructions provided by Huawei. The safety precautions
outlined in this document are only requirements of Huawei and do not include general safety
requirements. Huawei is not liable for any consequence that results from violation of regulations
pertaining to safe operations or safety codes pertaining to design, production, and equipment use.
This is a class A product. In a domestic environment this product may cause radio interference in which case the
user may be required to take adequate measures.
Take ESD protection measures during equipment installation and maintenance. For example, wear ESD gloves or
an ESD wrist strap.
Do not place other objects on the chassis.
WARNING
CAUTION
Laser beams will cause eye damage. Do not look into bores of optical modules or optical fibers without eye protection.
Do not install power cables while the power is on.
Do not turn on the power until you have finished installing the chassis and connecting cables.
