Huawei WiFi Q2 User Manual

4
How do I connect an add-on HUAWEI router (with H/Hi button) to my HUAWEI WiFi Q2's network?
Wired connection. Connect the WAN port of the add-on router to any port on the configured HUAWEI WiFi Q2 using an
Ethernet cable.
Pairing through the H button. Step 1) Place the add-on router (new or factory reset) within one meter of the configured
HUAWEI WiFi Q2 and connect it to the power supply. 2) When the indicator on the HUAWEI WiFi Q2 starts to flash, press
the H button on it. Wait until the indicator on the add-on router shows it is connected to the network.
Does HUAWEI WiFi Q2 support 5 GHz Wi-Fi? How do I connect to its 5 GHz Wi-Fi network?
5 GHz Wi-Fi is supported. The Wi-Fi names for 2.4 GHz and 5 GHz are the same by default. You will be automatically
connected to the faster Wi-Fi network. If you want to use 5 GHz Wi-Fi only, you can disable the Prioritize 5 GHz feature
by performing the following steps:
1) Connect your phone to the router's Wi-Fi.
2) Open the HUAWEI SmartHome app.
3) Go to Tools > Advanced settings > My Wi-Fi > Wi-Fi settings, and touch Prioritize 5 GHz to disable it.
You will find two Wi-Fi network names on your phone. Select the Wi-Fi name that ends with _5G to connect.
5

Huawei WiFi Q2 Specifications

General

Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1167 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	867 Mbit/s
Product type	Tabletop router
Product color	White
Ethernet LAN	Yes
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Memory card slot(s)	No
Ethernet LAN (RJ-45) ports	3
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	24 W
Processor model	Realtek RTL8197F + Realtek RTL8812BR + Hisilicon Hi5630 + HiSilicon Hi1151
Security algorithms	AES, TKIP, WPA-PSK, WPA2-PSK
DSL WAN	-
WAN connection type	RJ-45
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Cables included	AC, LAN (RJ-45)

Weight and Dimensions

Depth	75 mm
Width	112 mm
Height	183.5 mm
Weight	495 g
