49
11 Appendix
Technical Specifications
Default Settings
Item Specifications
Power supply 12 V DC, 0.5 A
Power consumption < 6 W
Ambient operating
temperature
0°C to 40°C
Ambient humidity 5% to 95% RH (non-condensing)
Dimensions (H x W x D)
32 mm x 180 mm x 126 mm (1.26 in. x 7.09 in. x 4.96 in.), antenna
excluded
Weight About 200 g
WLAN standard 802.11b, 802.11g, 802.11n (2.4GHz)
Wireless transmission
rate(2.4G)
802.11b Up to 11 Mbit/s
802.11g Up to 54 Mbit/s
802.11n (2T2R
antenna
technology)
Up to 300 Mbit/s
Parameter Default Value
LAN port IP address 192.168.3.1
LAN port subnet mask 255.255.255.0
User name to log in to the web
configuration page
admin
Password to log in to the web
configuration page
admin
WLAN name Labeled on the product cover
WLAN password Labeled on the product cover
