Wiring Diagrams
32
4-wire Heat/Cool System
5-wire Heat/Cool System
THERMOSTAT
G
W
Y
RHRC
Heat Relay
or Valve
Heat/Cool
Transformer
Fan
Relay
Cool
Contactor
Jumper
THERMOSTAT
G
W
Y
RHRC
Heat Relay
or Valve
Heat
Transformer
Fan
Relay
Cool
Contactor
Cool
Transformer
