English – 33
TECHNICAL DATA
1154580-49 Rev.2 2013-03-11
Recommended cutting equipment for USA
Following is a list of recommended cutting equipment for Husqvarna chainsaw models 135,135e,140,140e and 140e
TrioBrake. These chain saw models equipped with either of the listed bar and saw chain combination(s), fulfills the
requirements according to ANSI B175.1-2000 (Gasoline Powered Chain Saws - Safety Requirements).
The following list is the chain saw manufacturers recommendations. There may be other combinations available, which
will also achieve kickback reduction.
Chain saw models Husqvarna 135,135e,140,140e and 140e TrioBrake met the kickback performance requirements of
ANSI B175.1-2000 when tested with the combinations of bars and saw chains listed below. The saw chain Husqvarna
H37 is also classified as a low kickback saw chain since it met the requirements for low kickback saw chain outlined in
ANSI B175.1-2000. We recommend to use only the listed combinations of bars and chains for chain saw models
Husqvarna 135,135e,140,140e and 140e TrioBrake. Other chain saw models may not meet the kickback requirements
when equipped with the listed guide bar and saw chain combinations.
Recommended cutting equipment for Canada
Following is a list of recommended cutting equipment for the Husqvarna chain saw models 135, 135e, 140, 140e and
140e TrioBrake.
The listed combination(s) of powerhead, bar and saw chain meet all requirements outlined in Canadian Standards
Assosiation Z62.1-03 (Chain Saws) and Z62.3-04 (Chain Saw Kickback).
Furthermore the saw chain Husqvarna H37 is evaluated and listed as a Type C Low Kickback Saw Chain according to
the provisions in Z62.3-04.
Kickback information
The guide bar nose radius is determined by either the maximum number of teeth in the nose sprocket or the
corresponding maximum nose radius of a solid bar.
As we are listing the maximum guide bar nose radius, you may use a guide bar with smaller nose radius than in our list.
For guide bars of the same length, all sprocket-nose guide bars of the same pitch and having the same number of
sprocket teeth may be considered to have equivalent kickback energy.
Guide bar and chain combinations
The following recommended combinations of bar and saw chain are type approved for your chain saw.
Saw chain filing and file gauges
Guide bar Saw chain
Length, inch Pitch, inch Gauge, inch Max. nose radius Type Drive link count
14
3/8 0.050 9 T Husqvarna H37
52
16 56

Husqvarna 135 Specifications

General

Cylinder Displacement	40.9 cm³
Weight	4.4 kg
Sound Pressure Level	102 dB(A)
Sound Power Level	114 dB(A)
Bar Length	14 in
Chain Pitch	3/8 inch
Chain Gauge	0.05 in
Oil Tank Volume	0.25 liters
