Husqvarna 135 User Manual

KEY TO SYMBOLS
English
–
7
1154580-49 Rev.2 2013-03-11
Symbols on the machine:
WARNING! Chain saws can be
dangerous! Careless or improper use can
result in serious or fatal injury to the
operator or others.
Please read the operator’s manual
carefully and make sure you
understand the instructions before
using the machine.
Always wear:
• Approved protective helmet
• Approved hearing protection
• Protective goggles or a visor
Both of the operator ′ s hands must be
used to operate the chain saw.
Never operate a chain saw holding it
with one hand only.
Contact of the guide bar tip with any
object must be avoided.
Recommended cutting
equipment in this example:
- Bar length 14 inches
- Max. nose radius 9 Teeth
- Chain type Husqvarna
H37
Other approved bar and chain
combinations in Operator’s Manual.
Measured maximum kickback value
without triggering the chain brake.
WARNING! Kickback may occur when
the nose or tip of the guide bar touches
an object, and cause a lightning fast
reverse reaction, kicking the guide bar
up and towards the operator. May cause
serious personal injury.
Chain brake, activated (right) Chain
brake, not activated (left)
Refuelling.
Chain oil fill.
Ignition; choke: Set the choke control
in the choke position. This should
automatically set the stop switch to the
start position.
Air purge.
Other symbols/decals on the machine refer to special
certification requirements for certain markets.

Husqvarna 135 Specifications

General

Cylinder Displacement	40.9 cm³
Weight	4.4 kg
Sound Pressure Level	102 dB(A)
Sound Power Level	114 dB(A)
Bar Length	14 in
Chain Pitch	3/8 inch
Chain Gauge	0.05 in
Oil Tank Volume	0.25 liters
