3. Carry the robotic lawnmower by the handle under
the robotic lawnmower with the blade disc away
from the body.
CAUTION: Do not lift the robotic lawnmower
when it is parked in the charging station. It can
damage the charging station and/or the robotic
lawnmower. Press STOP and pull the robotic
lawnmower out of the charging station before
lifting it.
2.3.3 Maintenance
WARNING: When the robotic lawnmower is
turned upside down the main switch must
always be in the
0
position.
The main switch should be set in the
0
position
during all work on the mower’s chassis, such as
cleaning or replacing the blades.
CAUTION: Never use a high-pressure washer
or even running water to clean the robotic
lawnmower. Never use solvents for cleaning.
Inspect the robotic lawnmower each week and replace
any damaged or worn parts. See
Introduction -
maintenance on page 46
.
2.3.4 In the event of a thunderstorm
To reduce the risk of damage to electrical components
in the robotic lawnmower and its charging station, we
recommend that all connections to the charging station
are disconnected (power supply, boundary wire and
guide wires) if there is a risk of a thunderstorm.
1. Make sure the wires are marked with the supplied
markers to simplify reconnecting. The charging
station’s connections are marked AR, AL and G1.
2. Disconnect all connected wires and the power
supply.
3. Connect all the wires and the power supply if there
is no longer a risk of thunder. It is important that
each wire is connected to the right place.
8 - Safety 840 - 001 -
