Husqvarna M-ZT 61 User Manual

12
CONTROLS
This operator manual describes the Husqvarna
Zero Turn Rider. The rider is tted with a four-
stroke overhead valve engine.
Transmission from the engine is made via
2
10
11
12
3
4
6
7
8
9
belt-driven hydraulic pumps. Using the left and
right steering controls, the ow is regulated and
thereby the direction and speed.
1. Motion control levers
2. Park brake
3. Tracking knob
4. Fuel tank
5. Fuel shut off
6. Hydro release
7. Fuses
8. Choke control
9. Ignition switch
10. Service meter
11. Throttle control
12. Blade switch
13. Seat adjustment lever
14. Deck lift
15. Deck release pedal
5
13
14
1
15

Husqvarna M-ZT 61 Specifications

General

Engine Manufacturer	Kawasaki
Engine Name	FR Series
Engine Type	V-Twin
Engine Power	24 hp
Cutting Width	61 inches
Cutting Deck Type	Fabricated
Transmission Type	Hydrostatic
Weight	770 lbs
Deck Material	Steel
Cutting Methods	Mulching/Side discharge
Cutting Height	1.5 - 5 in
Warranty	3 years
Fuel Capacity	5 gallons
