English – 13
4 Appendices and schemas
4.1 Operating supplies
4.1.1 Recommended oil types
The pump is lled with 55 ml ARTL 32 from the
production.
In case of service where the oil must be changed,
Husqvarna recommends to use 80 ml Bartran HV 46.
Alternative oil types that are allowed:
• BP, Bartram HV 46
• Shell, Tellus T 46
• Exxon, Statoil Univis N 46
• Mobil Oil Mobil DTE 25.
4.1.2 Recommended lubrication
White grease for o-rings, sealings etc.:
• Silicone grease,
DOW CORNING(R) 55 O-RING LUBRICANT
4.1.3 Special tools
Appendices and schedules
1 2 3
Item Description Used for Article number
1 Screw driver, at For lock clamps N/A
2 Screw driver, PH2 For screws N/A
3 M4 Puller For valve seat 592 94 50-01
3 M8 Puller For valve seat 592 94 49-01
