16 – English
Gun is open - Control piston is closed. Micro switch is deactivated.
Motor starts.
Pump
3 BAR
Inlet
Non return valve
Outlet 3 BAR
3 BAR
4.2.6 Machine run
Machine runs (normal working pressure). Gun is open.
Pump
70-95 BAR
Inlet
Non return valve
Outlet 65-90 BAR
3 BAR
