567
Driving your vehicle
Trailer towing equipment
Hitches
✽
NOTICE
• The mounting hole for hitches are
located on both sides of the under-
body behind the rear tires.
• Install a trailer after removing the
under cover on the left side of the
vehicle. After using the trailer,
reinstall the under cover to its
original position.
M/T : Manual transaxle
A/T : Automatic transaxle
Engine
Item
1.6 Engine
M/T A/T
Maximum trailer
weight
kg (Ibs.)
Without brake
System
300
(661)
300
(661)
With brake System
300
(661)
300
(661)
Maximum permissible static
vertical load on the coupling device
kg (Ibs.)
75
(165)
Recommended distance from rear wheel
center to coupling point
mm (inch)
1070
(42.1)
â–
For countries with Euro 5 emission standards
OMD064021
