4. CHARGING MODES
HYBC-20 charger has ten (10) modes: STANDBY, 12V/2A, 12V/4A, 12V/6A, 12V/8A, 12V/10A, 12V/15A,
24V/3.5A, 24V/7.5A, 12V BOOST. Do not operate the charger until you confirm the appropriate charge mode
for your battery.
CAUTION: If you choose 24V Mode for 6V/12V battery, the 6V/12V battery will be damaged!
Mode Display POWER LED BOOST LED Explanation
STANDBY - Blink
Not charging or providing any power. If you want
charging to pause, press ON/OFF button and
it will enter STANDBY mode.
12V/2A 02A Keep on
Connected to12V battery, it can turn into 2A by pressing
CURRENT button. This mode is recommend
for 2-60AH batteries.
12V/4A 04A Keep on
Connected to 12V battery, it can turn into 4A by pressing
CURRENT button. This mode is recommend for
2-120AH batteries.
12V/6A 06A Keep on
Connected to 12V battery, it can turn into 6A by pressing
CURRENT button. This mode is recommend for
10-180AH batteries.
12V/8A 08A Keep on
Connected to 12V battery, it can turn into 8A by pressing
CURRENT button. This mode is recommend for
20-240AH batteries.
12V/10A 10A Keep on
Connected to12V battery, it can turn into 10A by pressing
CURRENT button. This mode is recommend
for 40-300AH batteries.
12V/15A 15A Keep on
Connected to 12V battery, it can turn into 15A by pressing
CURRENT button. This mode is recommend
for 50-400AH batteries.
24V/3.5A 3.5A Keep on
Connected to 24V battery, it can turn into 3.5A by
pressing CURRENT button. This mode is recommend for
14-115AH batteries.
24V/7.5A 7.5A Keep on
Connected to 24V battery, it can turn into 7.5A by
pressing CURRENT button. This mode is recommend for
25-200AH batteries.
BOOST FAS Keep on Keep on
Connected to 12V battery, it can enter BOOST Mode by
pressing BOOST button. It takes 5 minutes to charge.
!
