HYUNDAI 07
5. CHARGING STEPS
STEP 1: DIAGNOSIS (Check if battery has connected with the charger and also check battery voltage)
STEP 2: DESULPHATION (If battery voltage is too low, programs automatically generate pulsing current to
remove sulphate, up to 5 hours)
STEP 3: ANALYSE (Check if the battery voltage reaches to the threshold after desulphation, and charging
begins if the battery voltage is OK)
STEP 4: SOFT START (Charge with echelon constant current)
STEP 5: BULK (Charge with constant maximum current until battery voltage is reached to the threshold)
STEP 6: ABSORPTION (Provide gradually declining current charge for maximum battery voltage)
STEP 7: ANALYSE (Test if the battery can hold charge)
STEP 8: MAINTENANCE (Continuously monitor the battery, and charging current will intelligently adapt to
the variable battery voltage)
NOTICE: After full charging cycle, use this battery to start matched vehicle’s engine. If engine cannot be
activated (exclude the problem of vehicle itself), it indicates this batter has declined storage
capacity and need to be replaced.
Voltage(V)
1 2 3 4 5 6 7 8
Current(A)
Step
