Hyundai HYM40Li420SP User Manual

25
Battery
1. Plug the charger into an AC outlet 220-250V (normal household voltage).
2. Insert the battery into the slots of the charger and slide into place until the battery locks into
place.
3. The LED will flash green while the battery is charging.
4. Once the battery is fully charged, the LED indicator will show a steady green light.
5. Remove the battery by pressing and holding the latch button and sliding out of the charger.
6. Do not leave the battery on the charger. Remove it when it is fully charged.
7. Lithium-ion batteries have no memory effect - a partial charge will not damage your battery.
!
WARNING! Charge in a safe location away from moisture and heat sources!
The unit has an LED state of charge indicator on the handlebar.
4 LED lights lit = 100% battery power
3 LED lights lit = 75% battery power
2 LED lights lit = 50% battery power
1 LED light lit = 25% battery power
Checking Charge Status
Charging The Battery

Hyundai HYM40Li420SP Specifications

General

Nominal Voltage	40V
Battery Type	2.5Ah Lithium-ion
Cutting Height	25-75mm (6 Heights)
Motor Speed	2800-3600rpm
Height Adjustment	Single Lever
Cutting Width	415mm / 41.5cm
Grass Collector Capacity	45L
Measured Sound Power	84dB(A)
Guaranteed Sound Power	96dB(A)
Vibration Level	1.62m/s2, k=0.5m/s2

Weight and Dimensions

Wheel Size Front	152mm
Wheel Size Rear	178mm
Weight	21.9kg Including Battery
