Hyundai HYM40Li420SP User Manual

26
Removing / Emptying Grass Collector
If the grass collector is full, it should be emptied immediately.
1. Switch the motor off.
2. Wait until the blade stops.
3. Lift the rear discharge guard.
4. Remove the grass collector.
5. Lower the rear discharge guard down again.
6. Empty the grass collector.
7. Before re-fitting, remove any obstructions from the rear discharge chute.
Grass Collector

Hyundai HYM40Li420SP Specifications

General

Nominal Voltage	40V
Battery Type	2.5Ah Lithium-ion
Cutting Height	25-75mm (6 Heights)
Motor Speed	2800-3600rpm
Height Adjustment	Single Lever
Cutting Width	415mm / 41.5cm
Grass Collector Capacity	45L
Measured Sound Power	84dB(A)
Guaranteed Sound Power	96dB(A)
Vibration Level	1.62m/s2, k=0.5m/s2

Weight and Dimensions

Wheel Size Front	152mm
Wheel Size Rear	178mm
Weight	21.9kg Including Battery
