Your vehicle at a glance
42
ENGINE COMPARTMENT
1. Engine coolant reservoir...................7-22
2. Engine oil filler cap ...........................7-21
3. Brake/Clutch* fluid reservoir .............7-25
4. Air cleaner.........................................7-28
5. Fuse box ...........................................7-52
6. Negative battery terminal..................7-34
7. Positive battery terminal ...................7-34
8. Radiator cap .....................................7-24
9. Engine oil dipstick .............................7-21
10. Windshield washer fluid reservoir...7-26
* : if equipped
OLM079001
* The actual engine room in the vehicle may differ from the illustration.
