IBM 9009-22A Site And Hardware Planning

Table 100. SAS cable labeling (continued)
Name Connects Label
SAS YO cable
SAS adapter to a disk expansion
drawer
SAS X cable
Two SAS adapters to a disk
expansion drawer in a RAID
conguration
Cable section lengths
Figure 38. SAS external X cable assembly cable lengths
Figure 39. SAS external YO-cable assembly cable lengths
Site and hardware planning
115
