8231-E2B system parts
Indexed drawings show system part numbers of each part.
Rack final assembly
Table 86. Rack assembly part numbers
Index
number
CCIN Part number Units per
assembly
Description
1 74Y5193 1 EIA bracket (left)
2 39J0199 2 Attaching screw for EIA bracket (left)
3 59Y4919 2 Slide rail assembly
4 74Y7446 1 Top access cover assembly
5 59Y4822 1 Cable management arm assembly
6 74Y5194 1 EIA bracket (right)
7 39J0199 2 Attaching screw for EIA bracket (right)
204 Finding parts, locations, and addresses
